What are the characteristics of dc electronic loads?

1. It can display the measured current and voltage and other parameters in a specific mode in real time, without additional connection of voltmeter and ammeter, it can test the current output size of DC power supply, the test range is within 10-100A.

2.when the electronic load is in default mode, the same module can cooperate with the test, the current is the sum of the current of all equipment, the output power is the sum of the power of all equipment, but it should be noted that only parallel, not series.

3.Standard current mode is suitable for measuring CV state load adjustment rate, output voltage adjustment or dynamic load.

4. Standard voltage mode is used to measure CC load regulation rate of power supply, current regulation output or dynamic analog load.

5.in the control panel can adjust the current rise or fall rate change, to reduce the risk of power failure, or test the transient response characteristics of the power output.

6.When the DC electronic load is used to test the power supply, it should be noted that the positive and negative poles of the two should be correctly connected, not inversely connected.

7.electronic load with remote voltage measurement function, that is, equipped with weak current setting and port measurement, can reduce the partial voltage caused by the lead when measuring current, to prevent measurement error.
